Features |
Over load protection, automatic polarity |
| Display |
3 1/2 digits LCD 1999 counts |
| Range |
|
Range |
Ranges |
Accuracy |
|
DC Current |
200A
1000A |
+/- 1.5 % +15 digitt
+/- 2.0% + 5 digit |
|
AC Current |
200 A
1000 A |
+/- 1.5 % +15 digit
+/- 2.0 % + 5 digit |
|
DC Voltage |
200 mV,
200 V, 600 V |
+/- 1.0% +
1 digit |
|
AC Voltage |
200, 600 V |
+/- 1.0% + 2 digit |
|
Resistance |
2000 ohms |
+/- 1.0% + 1 digit |
|
| Diode test,
continuity test |
yes |
| Jaw opening size |
34 mm |
| Over range indication |
Display indicates 1 |
| MeasurementWeight |
230L X 70W X 36H in mm., 400 gms. Approx. |
| Extra |
Supplied with test leads,
carry case and
operating manual |
